PlumbMap – Visual Plumbing Layout of Bathroom & Kitchen
PlumbMap is a comprehensive visual plumbing map that clearly illustrates how water supply and drainage pipelines are expertly routed inside bathroom and kitchen walls. This tool helps homeowners, DIY enthusiasts, and plumbing students understand the hidden plumbing infrastructure that operates behind the scenes in every modern home.
Foundation
Plumbing Layout Overview
This detailed layout represents the complete internal plumbing system architecture of a bathroom. It comprehensively explains how water is supplied from the main line, systematically distributed to various fixtures, and efficiently drained through an organised pipeline routing system installed inside walls and beneath floors.
Understanding this layout is essential for maintenance, repairs, renovation planning, and troubleshooting common plumbing issues that arise in residential spaces.
Cold Water Supply Line
The cold water supply line is the primary pipeline that distributes water throughout the plumbing system. It supplies all bathroom and kitchen fixtures and provides a branch connection to the hot water heating system.
1
Cold Water Supply Line
Primary distribution pipeline
2
Multiple Outlets
Bathroom and kitchen fixtures
3
Branch Connection
Feeds hot water system
Hot Water Supply Line
The hot water line branches off from the main cold water supply and runs parallel as a completely separate pipeline system throughout the building. This dedicated line efficiently delivers heated water to all required outlets in both the bathroom and kitchen areas.
The hot water system typically includes a storage tank or instantaneous heater, pressure relief valves, and insulated pipes to maintain temperature and prevent heat loss during distribution to various fixtures.
Water Heating
Geyser or instant heater heats the branched cold water
Parallel Routing
Hot line runs alongside cold supply independently
Outlet Delivery
Delivers to bathroom taps, showers, and kitchen sink
Drainage System
Drainage System
The drainage system is strategically installed below floor level to utilise gravity for efficient wastewater flow. All wastewater from bathroom fixtures and kitchen sinks flows through specially designed sloped pipes that maintain a consistent gradient, ensuring smooth discharge and preventing blockages.
01
Collection Points
Wastewater collected from sinks, showers, toilets, and kitchen drains through trap fittings
02
Sloped Pipeline Network
Pipes installed at proper gradient (typically 1:40 to 1:80 slope) to enable gravity-driven flow
03
Common Outlet Junction
All drainage lines converge into a main soil stack or drainage pipe
04
External Disposal
Wastewater exits through common outlet to septic tank or municipal sewer system

Important: Proper venting is essential in drainage systems to prevent trap siphoning and ensure smooth wastewater flow. Vent pipes allow air circulation and maintain atmospheric pressure within the drainage network.
Project Details
PlumbMap Project Overview
PlumbMap is an innovative technical plumbing mapping project designed to demystify complex bathroom and kitchen plumbing systems. It provides a clear, digital interface to explain how these intricate networks function within modern homes.
Project Scope
PlumbMap aims to explain plumbing systems through a digital interface, making the hidden infrastructure accessible and understandable for various users.
Developed By
Created by Ateeq Farooq Khan as part of the ITI Plumber Trade curriculum, demonstrating practical application of plumbing knowledge.
Curated On
Content is curated using Linktree for easy navigation and presented digitally via Gamma.app, under the guidance of a dedicated Plumber Trade Instructor.
